Networking Specfications
10/100 Mbps RJ45 PoE Port 4
10/100 Mbps RJ45 Port 1
Gigabit RJ45/SFP Combo Ports --
EX Mode PoE (200M@10Mbps)* 2
Ethernet Performance
Switching Bandwidth 1 Gbps
Mac Table 2 K
Jumbo Frame 1536 Bytes
Auto-MDI/MDI-X, Auto-Negotiation Supported
Power Specifications
Power Input Voltage 100VAC ~ 240VAC
Max. PoE Output Power /Per Port Per Port 54VDC, Max. 30W
Total PoE Power Budget 120W
IEEE 802.3af/at Supported
Power Pin Assignment 1/2(+), 3/6(-)
PoE PD Auto Detection Supported
. Surge Protection/Each PoE port 12 KV
Surge Protection for AC Power 10 KV
General
Waterproof Rating IP67
Vandal Proof IK10
Operating Temperature -40°C ~ 60°C (-40°F ~ 140°F)
Operating Humidity % ~ 95% non-condensing
Dimensions 255.2 (W) x 199.9 (H) x 90 (D) mm
Weight 3.2 KG
Connectors M25 x 2
Certifications
EMC CE, FCC, VCCI, C-Tick Class A
Safety EN60950-1, IEC60950-1
Vibration IEC 60068-2-6
Shock IEC 60068-2-27
Freefall IEC 60068-2-32
Surge ITU-T K.21, IEC-61643-11
